Toyo Drive
Toyo Drive
| Performance | |
| Passenger capacity | 6 seats |
| Max.speed | 24km/h |
| Range(loaded) | 80km |
| Climbing Ability(loaded) | 18% |
| Braking Distance | ≤4.5m |
| Min.Turning Radius | 4.7m |
| Min.Clearance | 105mm |
| Recharge time | 8~10h |
| Dimensions | |
| L×W×H | 3400×1295×1900mm |
| cargo box size | 1100×550×300mm |
| F/R Tread | 870/980mm |
| Axle Distance | 2870mm |
| Curb Weight | 670kg |
| Max. loading weight | 400kg |
| Configurations | |
| Motor | separately excited 48V 3KW |
| Controller | Curtis 1204-404 48V 275A |
| Battery | Lead Acid Battery 8V145Ah×6pcs |
| Body | ABS Plastic |
| Roof | ABS Plastic |
| Windshield | One - piece see-through POLYCARBONAT glass |
| Seats | Sponge + artificial leather |
| Bumper | Front and back |
| Tire | Steel 18×8.50-8 6PR |
| Chassis | Welded tubular steel with rust-proof powder coat paint |
| Steering | Single reduction rack and pinion |
| Suspension | Independent front wheel suspension |
| Lighting system | 2 headlights, 2 front turn signals, 2 rear turn signals and 2 rear brake lights |
| Brake system | Rear and front drum pneumatic brake system,4-wheels Hydraulic pressure type |
| Driving mode | Rear wheel driving |
| Charger | Fully automatic high efficiency pulse, 25 Amp DC output at 48 volts; input AC 220V 50HZ , external charger |
| Dashboard | Forward/reverse switch, turn signal indicator, ignition key, headlight switch, horn button,,electric power consumption indicator,four cup holders |
