Toyo Drive
Toyo Drive
| Model | HT250 |
| Type | 4X4 wheeled type |
| W X D X H (mm) | 2930X1500X2000 |
| Wheel base (mm) | 1605/1730 |
| Front wheel (mm) | 1070/1170/1270 Adjustable |
| Rear wheel (mm) | 1000/1100/1200/1300 Adjustable |
| Min. ground clearance (mm) | 330 |
| When one-side braking (m) | 2.5±0.2 |
| No braking (m) | 2.9±0.2 |
| Tractor dry mass (kg) | 1400 |
| Front/Rear Ballast (kg) | 50/60 |
| Max. PTO Power (kw) | 19.9 |
| Transmission box | Mechanic gear box |
| Gear shifts | (4+1)X2 |
| Theoretical speed (km/h) | F2.07-31.54 R2.72-12.59 |
| Differential | Closed, 2 planetary gear |
| Differential lock | Jaw type |
| Engine Model | 3T30 |
| Engine Type | Vertical 4 stroke, water cooled |
| Number of Bores | 3 |
| Bore dia. X stroke (mm) | 85X95 |
| Combustion chamber | Direct injection |
| Rated Power (kw) | 22.06 |
| Fuel consumption (g/kw.h) | ≤248.9g/kw.h |
| Engine oil consumption (g/kw.h) | ≤2.04g/kw.h |
| Front tyre size | 6.00-16 |
| Rear tyre size | 9.50-24 |
| Steering system | Power steering |
| Brake | Shoe brake |
| Tri-point Hitch system | Rear mounted, ball-hinged |
| Max. lifting capacity (kN) | 4.96 |
| PTO type | Rear mounted, nonindependent |
| PTO Rev. (rpm) | 540/720 r/min |
